ZJHP type Pneumatic Diaphragm Single Seat Control Valve adopts top guide structure, This type of valve has a compact structure, small pressure drop loss, large flow rate, wide adjustable range, and high accuracy of flow characteristics, and complies with the IEC60534-2-1-2011 standard. The leakage of the regulating valve complies with ANSI FCI 70-2-2013 standard. The structure adopts a pressure cage type to facilitate quick replacement of the valve spool and valve seat. At the same time, the valve seat sealing line is double-sided, extending the service life of the valve.
Single seated control valve is equipped with a multi-spring diaphragm or cylinder actuator, which has a compact structure and large output force.
Single seated control valve Features
Size:DN20~DN600 1/2"-24"
Pressure:PN1.6MPa~ PN42 MPa 150LB-2500LB JIS 10K ~JIS 40K
End connection:RF RJ ,BW
Material:WCB,WC6,LCB ,CF8,CF8M,CF3M, LCB,904L, 316Ti , A105 ,F304,F316, Duplex stainless steel, Monel, Hastelloy, (Special Materials on Request)
Bonnet type: Normal type(P)：－45～＋250℃
Extend type with I type-High temperature type(EI)：＋250～＋566℃
Extend type with EII type--cryogenic type(EII)：－45～－196℃
Single seated control valve Trim type
Pressure-balanced spool
Flow characteristics: Equal Percentage ,Linear type
Leakage class:class IV(stand type ) class V, class VI
Adjustable ratio:50:1
Actuator type
- Pneumatic actuator:Pneumatic diaphragm actuator or pneumatic piston actuator
- Air supply: 3-7bar
- Failure position :Normally closed (NC),Normally open(NO)
Pneumatic Diaphragm Single Seat Control Valve structure
