Pneumatic diaphragm valve is based on the diaphragm serving as a power communication line, and the control system controls the medium flow by controlling the pressure difference.
When the pneumatic control signal acts on the pneumatic actuator, the action of the cylinder will cause the volume of the air chamber on the diaphragm to change, thereby regulating the flow rate.
Type:Pneumatic diaphragm control valve
Size:DN15~DN200 1/2"-8"
Pressure:PN1.6MPa 150LB
End connection:RF RJ
Material:HT200,WCB,WC6,CF8,CF8M,CF3M, LCB,904L, 316Ti Duplex stainless steel, Monel, Hastelloy, (Special Materials on Request)
Bonnet type: ：－20～＋150℃
Pneumatic diaphragm control valve Trim type
Trim:elastic diaphragm
Flow characteristics: quick to open
Adjustable ratio:30:1
Actuator type
- Pneumatic actuator:Pneumatic diaphragm actuator or pneumatic piston actuator
- Air supply: 3-7bar
- Failure position :Normally closed (NC),Normally open(NO)
FAQ
Q: What is your delivery date?
A: Valves (especially control valves) are products that need to be customized according to the customer's actual operating conditions (such as media type, working pressure, temperature, flow rate, etc.). For valve bodies of common materials and pressure specifications, we maintain a large inventory in advance. If the customer's requirements match the inventory specifications, production, assembly, and delivery can be completed within 10 days after confirming the order and parameters. If the valve required by the customer has special parameters such as material, pressure, and structure, requiring recasting of the valve body or customization of parts, the delivery time will be extended accordingly. However, we will clearly inform the customer of the estimated delivery time when accepting the order and promise that the delivery time will meet the customer's actual usage needs.
