A Miniature Electric Actuator is a compact, single-envelope electric drive built around a micro gear motor and an integrated control board, designed specifically for small-bore valves where a conventional electric actuator would be oversized. The unit accepts a standard 4-20 mA control signal and returns a 4-20 mA position feedback, so it modulates small control valves without a separate positioner or air supply. Output torque runs from 5 to 200 N·m, with a small thrust option of 300~2000 N, and control accuracy is about ±1% of full scale. Internal overload and over-temperature protection shut the motor down before it stalls or burns out on a jammed valve, while a standard manual override handwheel lets an operator hand-position the valve when power is lost. The housing is anti-corrosion anodized aluminum at IP65, suitable for clean rooms and lightly humid environments, and because no compressed-air tubing is required it eliminates the cost of running an air supply to small skids and bench-mounted valves.
Small valves are easy to buy for but hard to drive: an off-the-shelf micro actuator either is too weak for the stem or overpowers it and damages a delicate trim. We design the micro motor, reduction gear and control board in our actuator R&D lab rather than repacking a generic gearbox, and tune the output torque and signal logic to the specific small-bore valve travel, then endurance-test each unit for continuous start-stop cycling before shipment.
Specifications
|
Parameter |
Specification |
|
Control signal |
4-20 mA DC input / feedback |
|
Power supply |
AC220V / DC24V |
|
Output torque / thrust |
Small torque 5~200 N·m; small thrust 300~2000 N |
|
Control accuracy |
±1% FS |
|
Protection rating |
IP65 |
|
Housing material |
Anti-corrosion anodized aluminum alloy |
|
Manual device |
Standard emergency handwheel |
|
Ambient temperature |
-15°C ~ +75°C |
Applications
Laboratory small process lines
The tiny envelope fits bench-mounted piping and fume-cupboard skids, and the absence of an air line removes the need to install instrument-air service on a research rig.
Pharmaceutical miniature purified water control valves
The clean anodized housing, grease-light internals and IP65 sealing suit WFI and purified-water skids where a compact, low-maintenance drive is preferred over a pneumatic actuator with filter and regulator hardware.
HVAC small temperature-control valves
The fast 4-20 mA modulating response and handwheel override let the actuator track small temperature changes on heating coils and fan-coil units, with local manual operation if the building management signal drops.
Customization
- Output torque or thrust class selected against the small valve stem force
- Signal logic and feedback scaling configured for the customer's control system
- Supplied as a matched set with our small-bore control valves
- Manual override handwheel fitted as standard
Packaging & Transportation
Miniature actuators are packed in foam-lined cartons with the handwheel and terminals protected. Before dispatch we run continuous start-stop endurance and signal-accuracy checks, and we send packing photos, a packing list and the customs documents with the order.
FAQ
Q: What are your customization and MOQ terms?
A: There is no strict MOQ. For small custom batches the customer covers the tooling cost; for larger orders the factory absorbs it. We adjust torque rating and signal logic to match the requested small valve.
Q: What are your payment terms?
A: As a source manufacturer we offer factory pricing. Payment is by T/T. A deposit is required for custom orders; the deposit ratio depends on the level of customization and is negotiable for standard items.
Q: What is the service process?
A: After inquiry we quote, the customer provides the working-condition parameters (valve size, pressure drop, signal), our engineers issue a calculation sheet and 2D/3D sample drawings, we confirm price and drawings, then sign the supply contract.
